Options
8.19 K88, Safe Brake Adapter SBA 230 V AC
Fast de-energization
Some brake rectifier types are equipped with two additional connections for switching the
brake load on the DC side. This allows the brake coil to be quickly deenergized, i.e. braking
starts earlier.
The Safe Brake Adapter supports such a fast de-energization using the two additional
connections -X15:1 and -X15:2. This function does not belong to the safe brake control.
Notes
Note
Replacement fuses
The order numbers for spare fuses can be taken from the spare parts list supplied.
Note
The integrated safety functions, starting from the Safety Integrated (SI) input terminals of the
SINAMICS components (Control Unit, Motor Module), satisfy the requirements according to
EN 61800-5-2, EN 60204-1, DIN EN ISO 13849-1 Category 3 (formerly EN 954-1) for
Performance Level (PL) d and IEC 61508 SIL2.
With the Safe Brake Adapter (option K88), the requirements specified in EN 61800-5-2, EN
60204-1, DIN EN ISO 13849-1 Category 3 (formerly EN 954-1) as well as for Performance
Level (PL) d and IEC 61508 SIL 2 are fulfilled.
Note
Safety Integrated Function Manual
Detailed and comprehensive instructions and information for the Safety Integrated functions
can be found in the associated Function Manual. This manual is available as additional
documentation on the customer DVD supplied with the device.
