Extended-Error Code
Error Code (hex): (hex):
0x00 none
0x02 none
0x08 none
0x11 none
0x13 none
0x15 none
0x19 none
2. On the Communication tab of the Message Configuration, set the Path in the same manner as
in the MSG that identifies the mail relay server.
Click Apply.
Click OK.
Understanding Email Status Codes
Examine the destination element of the email MSG to see whether the email
was successfully delivered to the mail relay server. This indicates that the
mail relay server placed the email message in a queue for delivery. It does
not mean the intended recipient successfully received the email message.
Possible codes that could be in this destination element are:
Description:
Delivery successful to the mail relay server.
Resource unavailable. The email object was unable to obtain memory resources to initiate the
SMTP session.
Unsupported Service Request. Make sure the service code is 0x4B and the Class is 0x32F.
Reply data too large. The Destination string must reserve space for the SMTP server reply
message. The maximum reply can be 470 bytes.
Configuration data size too short. The Source Length is less than the Source Element string
size plus the 4-byte length. The Source Length must equal the Source Element string size + 4.
Configuration data size too large. The Source Length is greater than the Source Element
string size plus the 4-byte length. The Source Length must equal the Source Element string
size + 4.
Data write failure. An error occurred when attempting to write the SMTP server address
(attribute 4) to non-volatile memory.
Communicating with Devices on an EtherNet/IP Link 6-29
