B-2 Access Procedures
Opening Door Over Power
Structure and Main Control
Board
Removing the Control
Cassette from Frame 1-6
Size Drives
B
C
B
Task Description
Open the door of the power structure and disconnect the cables that
A
connect to the main board
Loosen screws on face of cassette
B
Remove the cassette
C C
A
=
Frames 1-4
Locate the slot in the upper left corner. Slide
the locking tab up and swing the cover open.
Special hinges allow cover to move away from
drive and lay on top of adjacent drive (if
present).
Frame 5
Slide the locking tab up, loosen the right-hand
cover screw and remove.
Frame 6
Loosen 2 screws at bottom of drive cover.
Carefully slide bottom cover down & out.
Loosen the 2 screws at top of cover and
remove.
