Condition: Status:
solid red held in reset
self-test
major fault
flashing red updating firmware
Condition: Status:
off not initialized
flashing green no CIP
connections
established
solid green CIP connections
established
solid red duplicate IP
address
flashing red/green self-test
Condition: Status:
off no link
flashing green self-test
data transmission
and reception
solid green link OK
Indicates:
The controller is holding the port in reset or the
controller is faulted.
The port is performing its power-up self-test.
An unrecoverable fault has occurred.
The port firmware is being updated.
Network Status (NS) indicator
Indicates:
The port does not have an IP address and is
operating in BOOTP mode.
The port has an IP address, but no CIP connections
are established.
The port has an IP address and CIP connections
(Class 1 or Class 3) are established.
The port has detected that the assigned IP address is
already in use.
The port is performing its power-up self-test.
Link Status (LNK) indicator
Indicates:
The port is not connected to a powered Ethernet
device.
The port cannot communicate on Ethernet.
The port is performing its power-up self-test.
The port is communicating on Ethernet.
The port is connected to a powered Ethernet device.
The port can communicate on Ethernet.
DriveLogix5730 Controller Specifications
Recommended Action:
Clear the controller fault.
Replace the controller.
Normal operation during power-up. No action
required.
Cycle power to the controller.
Replace the controller.
Normal operation during firmware update. No
action required.
Recommended Action:
Verify that the BOOTP server is running.
Normal operation if no connections are
configured. No action required.
If connections are configured, check connection
originator for connection error code.
Normal operation. No action required.
Verify that all IP addresses are unique.
Normal operation during powerup.
Recommended Action:
Verify that all Ethernet cables are connected.
Verify that Ethernet switch is powered.
Normal operation during powerup.
Normal operation.
No action required.
Normal operation.
No action required.
