6-10 Communicating with Devices on an EtherNet/IP Link
1. From the Communications menu, select Configure Drivers.
2.
Configuring the EtherNet/IP Communications Driver
Important: EtherNet/IP only works within the local subnet and with
EtherNet/IP devices (not Ethernet control products).
To configure the AB_ETH Ethernet communication driver perform the
following steps in RSLinx:
Select EtherNet/IP Driver from the list of
Available Driver Types.
Then Click Add New.
After you create the driver, configure it to correspond to the Ethernet port on the
Embedded EtherNet/IP option board.
3. Selecte the default driver name (i.e. AB-ETHIP-1) or
type in your own name.
Then Click OK.
