Installing the
Communications
Daughtercard
Task
A
B
C C
Important: This procedure can be performed without
removing the cassette, if the Logix
Expansion Board is already installed.
Description
Align circuit board in Communications
Daughtercard with rail on Daughtercard slot
Insert the Communications Daughtercard
Tighten screws (7-10 lb.-in.)
Access Procedures
C
C
=
A
A
B
B-9
