Rockwell Automation Allen-Bradley GuardLogix 5580 Installation Instructions Manual

Installation Instructions
Original Instructions
GuardLogix 5580 Controllers
Catalog Numbers 1756-L81ES, 1756-L81ESK, 1756-L82ES, 1756-L82ESK, 1756-L83ES, 1756-L83ESK, 1756-L84ES, 1756-L84ESK,
1756-L8SP, 1756-L8SPK
Topic
Product Advisories
Parts List
Required System Components
Product Dimensions
Connectors and Status Indicators
Install the Controller
Install the SD Card
Connect to an EtherNet/IP Network
Confirm Installation
Specifications
Additional Resources
The GuardLogix® 5580 controllers help enable faster system performance, capacity, productivity, and security to help meet the growing demands of smart machines and
equipment for manufacturing.
• Integrated Motion over EtherNet/IP
• 1 Gb embedded Ethernet port enables high performance, communications, I/O, and motion control.
• Secure Digital (SD) card provides optional nonvolatile memory to store user program and tag data on the controller.
• Studio 5000 Automation Engineering & Design Environment® provides ease of system design and commissioning.
• Digitally signed and encrypted firmware helps protect against malicious intent.
• FactoryTalk® Security provides centralized authentication and access control by verifying the identity of each user-access attempt to the system.
• Display provides enhanced diagnostics and troubleshooting.
The GuardLogix controller is made up of a primary controller and a safety partner, for SIL 3 applications, that function together in a 1oo2 architecture. With a safety partner
installed, GuardLogix controllers are:
• Type-approved and certified for use in safety applications up to and including SIL 3 per IEC 61508.
• EC Type-approved for use in safety applications up to and including SIL CL3 per IEC 62061.
• EC Type-approved for use in safety applications up to and including Performance Level PLe (Category 4) per ISO 13849-1. When used without a safety partner
installed, SIL CL2 and PLd (Category 3) are achievable.
Summary of Changes
This manual contains new and updated information as indicated in the following table.
Topic
Added Plug Attention Statement
Specifications
TM
for up to 256 axes.
Page
3
4
5
5
6
6
7
7
7
8
9
Page
6
8
