Communicating with Devices on an ControlNet Link
Device:
remote adapter
"FLEX_io_adapter"
remote "input_module" in slot 0
rack-optimized connection
remote "output_module" in slot 1
rack-optimized connection
remote "combo_analog" in slot 2
direct connection
Example Tag Names (automatically created by the
software):
FLEX_io_adapter:I
FLEX_io_adapter:I.SlotStatusBits
FLEX_io_adapter:I.Data
FLEX_io_adapter:O
FLEX_io_adapter:O.Data
FLEX_io_adapter:0:C
FLEX_io_adapter:0:C.Config
FLEX_io_adapter:0:C.DelayTime_0
FLEX_io_adapter:0:C.DelayTime_1
FLEX_io_adapter:0:C.DelayTime_2
FLEX_io_adapter:0:C.DelayTime_3
FLEX_io_adapter:0:C.DelayTime_4
FLEX_io_adapter:0:C.DelayTime_5
FLEX_io_adapter:0:I
FLEX_io_adapter:1:C
FLEX_io_adapter:1:C.SSData
FLEX_io_adapter:1:O
FLEX_io_adapter:1:O.Data
FLEX_io_adapter:2:C
FLEX_io_adapter:2:C.InputFIlter
FLEX_io_adapter:2:C.InputConfiguration
FLEX_io_adapter:2:C.OutputConfiguration
FLEX_io_adapter:2:C.RTSInterval
FLEX_io_adapter:2:C.SSCh0OuputData
FLEX_io_adapter:2:C.SSCH1OutputData
FLEX_io_adapter:2:I
