De-energizing the Drive to
Connect or Disconnect a
Cable
About this Chapter
System Requirements
Configuring DriveLogix Motion
ATTENTION: Severe injury or death can result from electrical
!
shock or burn. Verify that the voltage on the bus capacitors has
discharged before connecting to the communication ports.
Measure the DC bus voltage at the +DC & -DC terminals on the
Power Terminal Block. The voltage must be zero.
During the process of configuring DriveLogix motion you will need to
connect or disconnect a programming or network cable at the controller.
You should do this only if the drive is de-energized.
1. Turn off and lock out input power. Wait five minutes.
2. Verify that there is no voltage at the drive's input power terminals.
3. Measure the DC bus voltage at the +DC & -DC terminals on the Power
Terminal Block. The voltage must be zero.
4. Connect or disconnect the programming or network cable.
5. Turn power back on and proceed with configuring DriveLogix motion.
This chapter introduces DriveLogix5730 motion. The steps in this chapter
provide the minimum settings required to begin testing DriveLogix motion.
• PowerFlex 700S Phase II Drive with firmware revision 1.XX or higher
• DriveLogix5730 Controller with firmware revision 13.XX or higher
• DriveExecutive programming software version 3.02 or higher
• RSLogix 5000 programming software version 13 or higher
4
