system overhead
continuous task
system overhead
continuous task
periodic task
system overhead
continuous task
Understanding the Virtual
Backplane
If you increase the time slice to 20%, the system overhead interrupts the
continuous task every 4 ms (of continuous task time).
1 ms
4 ms 4 ms
5
elapsed time (ms)
If you increase the time slice to 50%, the system overhead interrupts the
continuous task every 1 ms (of continuous task time).
1 ms
1 ms
5
elapsed time (ms)
If the controller only contains a periodic task(s), the system overhead
timeslice value has no effect. System overhead runs whenever a periodic
task is not running.
5
elapsed time (ms)
The DriveLogix5730 system has a five-slot virtual backplane. The
controller, drive and other components occupy different assigned slots on
the backplane.
Slot 0
DrvieLogix5730
Controller
1 ms 1 ms
4 ms
10 15
10 15
10 15
Virtual Backplane
Slot 1 Slot 2
Embedded PowerFlex 700S
EtherNet Option Drive
What is DriveLogix5730?
1 ms
4 ms 4 ms
20
20
20
Slot 3 Slot 4
Compact I/O NetLinx
Daughtercard
1-11
