Parameter Description
8-31 Address
Range:
Size related
*
3 3
8-32 Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
*
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
Default refers to the FC Protocol.
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-34 Estimated cycle time
Range:
0 ms [0 -
*
1000000 ms]
8-35 Minimum Response Delay
Range:
Size related
*
ms]
84
Function:
[ 1. - 255. ] Enter the address for the FC
(standard) port.
Valid range: 1 - 126.
Function:
Baud rates 9600, 19200, 38400 and 76800
baud are valid for BacNet only.
Function:
Parity and Stop Bits for the protocol
8-30 Protocol using the FC Port. For
some of the protocols, not all
options will be visible. Default
depends on the protocol selected.
Function:
In a noisy environments, the interface may
be blocked by due to overload of bad
frames. This parameter specifies the time
between two consecutive frames on the
network. If the interface does not detect
valid frames in that time it flushes the
receive buffer.
Function:
[ 5. - 10000. Specify the minimum delay time
between receiving a request and
transmitting a response. This is
used for overcoming modem
turnaround delays.
MG.11.CC.02 - VLT
®
VLT HVAC Drive Programming Guide
8-36 Maximum Response Delay
Range:
Size related
8-37 Maximum Inter-Char Delay
Range:
Size related
3.9.4 8-4* Telegram Selection
8-40 Telegram Selection
Option:
[1] Standard telegram 1
*
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
8-42 PCD write configuration
Range:
Application dependent
8-43 PCD read configuration
Range:
Application dependent
®
is a registered Danfoss trademark
Function:
[ 11. - 10001. Specify the maximum permissible
*
ms] delay time between transmitting a
request and receiving a response.
Exceeding this delay time will cause
control word time-out.
Function:
[ 0.00 - 35.00 Specify the maximum permissible
*
ms] time interval between receipt of
two bytes. This parameter activates
time-out if transmission is
interrupted.
Function:
Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
[0 - 9999 ]
*
[0 - 9999 ]
*
Function:
Function:
