How to Programme
5.
Change '0' to '1' by using the [
6.
Use the [
2 2
7.
Change '2' to '0' with the [
8. Press [OK]
The new ramp-down time is now set to 100 sec.
It is recommended to do the set-up in the order listed.
NOTE
A complete description of the function is found in the
parameter sections of this manual.
Illustration 2.5 Quick Menu View
The Quick Setup menu gives access to the 18 most
important setup parameters of the frequency converter.
After programming the frequency converter will, in most
cases, be ready for operation. The 18 Quick Setup
parameters are shown in the table below. A complete
description of the function is given in the parameter
description sections of this manual.
Parameter
0-01 Language
1-20 Motor Power [kW]
1-21 Motor Power [HP]
1-22 Motor Voltage*
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-28 Motor Rotation Check
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]*
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]*
3-19 Jog Speed [RPM]
3-11 Jog Speed [Hz]*
5-12 Terminal 27 Digital Input
5-40 Function Relay**
Table 2.1 Quick Setup parameters
*The display showing depends on choices made in 0-02 Motor Speed
Unit and 0-03 Regional Settings. The default settings of 0-02 Motor
Speed Unit and 0-03 Regional Settings depend on which region of
16
VLT
▲
] button
▶
] button to highlight the digit '2'
▼
] button
40.0% 4.84 A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
[Units]
[kW]
[HP]
[V]
[Hz]
[A]
[RPM]
[Hz]
[s]
[s]
[RPM]
[Hz]
[RPM]
[Hz]
[RPM]
[Hz]
MG.11.CC.02 - VLT
®
HVAC Drive Programming Guide
the world the frequency converter is supplied to but can be re-
programmed as required.
** 5-40 Function Relay, is an array, where one may choose between
Relay1 [0] or Relay2 [1]. Standard setting is Relay1 [0] with the
default choice Alarm [9].
See the parameter description in the section Commonly Used
Parameters.
For a detailed information about settings and
programming, please see the VLT
Programming Guide, MG.11.CX.YY
x=version number
y=language
1(1)
NOTE
If [No Operation] is selected in 5-12 Terminal 27 Digital
Input, no connection to +24V on terminal 27 is necessary
to enable start.
If [Coast Inverse] (factory default value) is selected in
5-12 Terminal 27 Digital Input, a connection to +24V is
necessary to enable start.
®
