Parameter Description
10-13 Warning Parameter
Range: Function:
0 [0 - 65535 ] View a DeviceNet-specific Warning word. One
*
bit is assigned to every warning. Please refer
to the DeviceNet Operating Instructions (MG.
33.DX.YY) for further information.
Bit: Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5 CAN bus off
6 I/O send error
7 Initialisation error
8 No bus supply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Read only from LCP
Option: Function:
Select the reference source in Instance 21/71 and
20/70.
[0] Off Enables reference via analog/digital inputs.
*
[1] On Enables reference via the fieldbus.
10-15 Net Control
Read only from LCP
Option: Function:
Select the control source in Instance 21/71 and 20/70.
[0] Off Enables control via analog/digital inputs.
*
[1] On Enable control via the fieldbus.
3.11.4 10-2* COS Filters
10-20 COS Filter 1
Range: Function:
0 [0 - 65535 ] Enter the value for COS Filter 1 to set up the
*
filter mask for the Status Word. When
operating in COS (Change-Of-State), this
function filters out bits in the Status Word
that should not be sent if they change.
®
VLT HVAC Drive Programming Guide
10-21 COS Filter 2
Range:
0
10-22 COS Filter 3
Range:
0
10-23 COS Filter 4
Range:
0
3.11.5 10-3* Parameter Access
Parameter group providing access to indexed parameters
and defining programming set-up.
10-31 Store Data Values
Option:
[0] Off
[1] Store all
[2] Store all
10-33 Store Always
Option: Function:
[0] Off Deactivates non-volatile storage of data.
[1] On Stores parameter data received via DeviceNet in
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Function:
[0 - 65535 ] Enter the value for COS Filter 2, to set up the
*
filter mask for the Main Actual Value. When
operating in COS (Change-Of-State), this
function filters out bits in the Main Actual
Value that should not be sent if they change.
Function:
[0 - 65535 ] Enter the value for COS Filter 3, to set up the
*
filter mask for PCD 3. When operating in COS
(Change-Of-State), this function filters out bits
in PCD 3 that should not be sent if they
change.
Function:
[0 - 65535 ] Enter the value for COS Filter 4 to set up the
*
filter mask for PCD 4. When operating in COS
(Change-Of-State), this function filters out bits
in PCD 4 that should not be sent if they
change.
Function:
Parameter values changed via DeviceNet are not
automatically stored in non-volatile memory. Use
this parameter to activate a function that stores
parameter values in the EEPROM non-volatile
memory, so changed parameter values will be
retained at power-down.
Deactivates the non-volatile storage function.
Stores all parameter values from the active set-up
setups in the non-volatile memory. The selection returns
to Off [0] when all values have been stored.
Stores all parameter values for all set-ups in the
setups non-volatile memory. The selection returns to Off
[0] when all parameter values have been stored.
EEPROM non-volatile memory as default.
