How to Programme
Function Set-ups parameters
The Function Set-ups parameters are grouped in the following way
2 2
Q3-10 Adv. Motor Settings
1-90 Motor Thermal Protection
1-93 Thermistor Source
1-29 Automatic Motor Adaptation
(AMA)
14-01 Switching Frequency
4-53 Warning Speed High
Q3-20 Digital Reference
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
18
®
VLT HVAC Drive Programming Guide
Q3-1 General Settings
Q3-11 Analog Output
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min
Scale
6-52 Terminal 42 Output Max
Scale
Q3-2 Open Loop Settings
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Q3-12 Clock Settings
0-70 Date and Time
0-71 Date Format
0-72 Time Format
0-74 DST/Summertime
0-76 DST/Summertime Start
0-77 DST/Summertime End
Q3-21 Analog Reference
3-02 Minimum Reference
3-03 Maximum Reference
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low Ref./Feedb. Value
6-15 Terminal 53 High Ref./Feedb. Value
Q3-13 Display Settings
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
