Danfoss VLT Series Programming Manual page 33

Parameter Description
0-32 Custom Readout Max Value
Range:
100.00 Custom-
ReadoutUnit
*
3 3
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter it is possible to write an individual
*
0 ] text string for display in the LCP or to be read via
serial communication. If to be displayed permanently
select Display Text 1 in 0-20 Display Line 1.1 Small,
0-21 Display Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3 Large.
Use the [
character. Use the [
cursor. When a character is highlighted by the cursor,
it can be changed. Use the [
LCP to change a character. A character can be
inserted by placing the cursor between two
characters and pressing [
0-38 Display Text 2
Range: Function:
0 [0 - In this parameter it is possible to write an individual
*
0 ] text string for display in the LCP or to be read via
serial communication. If to be displayed permanently
select Display Text 2 in 0-20 Display Line 1.1 Small,
0-21 Display Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3 Large.
Use the [
character. Use the [
cursor. When a character is highlighted by the cursor,
this character can be changed. A character can be
inserted by placing the cursor between two
characters and pressing [
0-39 Display Text 3
Range: Function:
0 [0 - In this parameter it is possible to write an individual
*
0 ] text string for display in the LCP or to be read via
serial communication. If to be displayed permanently
select Display Text 3 in 0-20 Display Line 1.1 Small,
0-21 Display Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3 Large.
Use the [
character. Use the [
cursor. When a character is highlighted by the cursor,
this character can be changed. A character can be
32
VLT
Function:
[ par. 0-31 - This parameter sets the max
999999.99 value to be shown when
CustomRea- the speed of the motor has
doutUnit] reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
▲ ▼
] or [ ] buttons on the LCP to change a
◀ ▶
] and [ ] buttons to move the
▲ ▼
] or [ ] buttons on the
▲ ▼
] or [ ].
▲ ▼
] or [ ] buttons on the LCP to change a
◀ ▶
] and [ ] buttons to move the
▲ ▼
] or [ ].
▲ ▼
] or [ ] buttons on the LCP to change a
◀ ▶
] and [ ] buttons to move the
MG.11.CC.02 - VLT
®
HVAC Drive Programming Guide
0-39 Display Text 3
Range:
3.2.5 0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option:
[0] Disabled
[1] Enabled
*
[2] Password
[3] Enabled without
OFF
[4] Password without
OFF
[5] Enabled with OFF
[6] Password with OFF
0-41 [Off] Key on LCP
Option:
[0] Disabled
[1] Enabled
*
[2] Password
[3] Enabled without
OFF
[4] Password without
OFF
[5] Enabled with OFF
[6] Password with OFF
®
is a registered Danfoss trademark
Function:
inserted by placing the cursor between two
▲ ▼
characters and pressing [ ] or [
Function:
No function
[Hand on] Key enabled
Avoid unauthorized start in Hand
mode. If 0-40 [Hand on] Key on LCPis
included in the My Personal Menu,
then define the password in
0-65 Personal Menu Password.
Otherwise define the password in
0-60 Main Menu Password.
Function:
No function
[Off] Key is enabled
Avoid unauthorized stop. If 0-41 [Off]
Key on LCP is included in the My
Personal Menu, then define the
password in 0-65 Personal Menu
Password. Otherwise define the
password in 0-60 Main Menu
Password.
].
