Danfoss VLT Series Programming Manual page 100

Parameter Description
13-02 Stop Event
Option: Function:
[8] Below I low See parameter group 5-3* for further
description.
[9] Above I high See parameter group 5-3* for further
description.
[10] Out of speed range
[11] Below speed low See parameter group 5-3* for further
description.
[12] Above speed high See parameter group 5-3* for further
description.
[13] Out of feedb. range See parameter group 5-3* for further
description.
[14] Below feedb. low See parameter group 5-3* for further
description.
[15] Above feedb. high See parameter group 5-3* for further
description.
[16] Thermal warning See parameter group 5-3* for further
description.
[17] Mains out of range See parameter group 5-3* for further
description.
[18] Reversing See parameter group 5-3* for further
description.
[19] Warning See parameter group 5-3* for further
description.
[20] Alarm (trip) See parameter group 5-3* for further
description.
[21] Alarm (trip lock) See parameter group 5-3* for further
description.
[22] Comparator 0 Use the result of comparator 0 in the
logic rule.
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic
rule.
®
VLT HVAC Drive Programming Guide
13-02 Stop Event
Option:
[31]
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[44]
[45]
[46]
[47]
[48]
[50]
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Function:
SL Time-out 1 Use the result of timer 1 in the logic
rule.
SL Time-out 2 Use the result of timer 2 in the logic
rule.
Digital input DI18 Use the value of DI18 in the logic
rule (High = TRUE).
Digital input DI19 Use the value of DI19 in the logic
rule (High = TRUE).
Digital input DI27 Use the value of DI27 in the logic
rule (High = TRUE).
Digital input DI29 Use the value of DI29 in the logic
rule (High = TRUE).
Digital input DI32 Use the value of DI32 in the logic
rule (High = TRUE).
Digital input DI33 Use the value of DI33 in the logic
rule (High = TRUE).
Start command This event is TRUE if the frequency
converter is started by any means
(either via digital input, fieldbus or
other).
Drive stopped This event is TRUE if the frequency
converter is stopped or coasted by
any means (either via digital input,
fieldbus or other).
Reset Trip This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and the reset button is
pressed.
Auto Reset Trip This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
OK Key This event is TRUE if the OK key on
the LCP is pressed.
Reset Key This event is TRUE if the Reset key on
the LCP is pressed.
Left Key This event is TRUE if the Left key on
the LCP is pressed.
Right Key This event is TRUE if the Right key on
the LCP is pressed.
Up Key This event is TRUE if the Up key on
the LCP is pressed.
Down Key This event is TRUE if the Down key
on the LCP is pressed.
Comparator 4 Use the result of comparator 4 in the
logic rule.
