Parameter Description
21-35 Ext. 2 Setpoint
Range:
0.000 ExtPID2Unit
3 3
21-37 Ext. 2 Reference [Unit]
Range:
0.000
ExtPID2Unit
*
21-38 Ext. 2 Feedback [Unit]
Range:
0.000 ExtPID2Unit
21-39 Ext. 2 Output [%]
Range:
0 % [0 - 100 %]
*
3.19.5 21-4* Closed Loop 2 PID
21-40 Ext. 2 Normal/Inverse Control
Option:
See 21-20 Ext. 1 Normal/Inverse Control for details.
[0] Normal
[1] Inverse
21-41 Ext. 2 Proportional Gain
Range:
0.01 [0.00 - 10.00 ] See 21-21 Ext. 1 Proportional Gain for
*
21-42 Ext. 2 Integral Time
Range:
10000.00 s
*
21-43 Ext. 2 Differentation Time
Range:
0.00 s [0.00 - 10.00 s] See 21-23 Ext. 1 Differentation Time for
*
21-44 Ext. 2 Dif. Gain Limit
Range:
5.0 [1.0 - 50.0 ]
*
144
Function:
[-999999.999 - See 21-15 Ext. 1
*
999999.999 Setpoint for details.
ExtPID2Unit]
Function:
[-999999.999 - See 21-17 Ext. 1
999999.999 Reference [Unit], Ext. 1
ExtPID2Unit]
Reference [Unit], for
details.
Function:
[-999999.999 - See 21-18 Ext. 1
*
999999.999 Feedback [Unit] for
ExtPID2Unit] details.
Function:
See 21-19 Ext. 1 Output [%] for details.
Function:
Function:
details.
Function:
[0.01 - 10000.00 s] See 21-22 Ext. 1 Integral Time
for details.
Function:
details.
Function:
See 21-24 Ext. 1 Dif. Gain Limit for details.
MG.11.CC.02 - VLT
®
VLT HVAC Drive Programming Guide
3.19.6 21-5* Closed Loop 3 Ref/Fb
21-50 Ext. 3 Ref./Feedback Unit
Option:
[0] None
[1] %
*
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
®
is a registered Danfoss trademark
Function:
See 21-10 Ext. 1 Ref./Feedback Unit for details.
