Parameter Description
3.8.5 6-4* Analog Input 4 MCB 101
Parameter group for configuring the scale and limits for
analog input 4 (X30/12) placed on option module MCB
101.
3 3
6-40 Terminal X30/12 Low Voltage
Range:
0.07 V [
*
6-41 V]
6-41 Terminal X30/12 High Voltage
Range:
10.00 V [
*
10.00 V]
6-44 Term. X30/12 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
6-45 Term. X30/12 High Ref./Feedb. Value
Range:
100.000 [-999999.999 -
*
999999.999 ]
6-46 Term. X30/12 Filter Time Constant
Range:
0.001 s [0.001 -
*
10.000 s]
6-47 Term. X30/12 Live Zero
Option:
[0] Disabled
*
[1] Enabled
78
Function:
0.00 - par. Sets the analog input scaling value to
correspond to the low reference/
feedback value set in 6-44 Term.
X30/12 Low Ref./Feedb. Value.
Function:
par. 6-40 - Sets the analog input scaling value to
correspond to the high reference/
feedback value set in 6-45 Term.
X30/12 High Ref./Feedb. Value.
Function:
Sets the analog output scaling
value to correspond to the low
voltage value set in 6-40 Terminal
X30/12 Low Voltage.
Function:
Sets the analog input scaling
value to correspond to the high
voltage value set in
6-41 Terminal X30/12 High
Voltage.
Function:
A 1 st order digital low pass filter time
constant for suppressing electrical
noise on terminal X30/12.
6-46 Term. X30/12 Filter Time Constant
cannot be changed while the motor is
running.
Function:
This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the
analog outputs are used as part of a decentral
I/O system (e.g. when not part of any frequency
converter related control functions, but feeding a
Building Management System with data)
MG.11.CC.02 - VLT
®
VLT HVAC Drive Programming Guide
3.8.6 6-5* Analog Output 1
Parameters for configuring the scaling and limits for
analog output 1, i.e. Terminal 42. Analog outputs are
current outputs: 0/4-20mA. Common terminal (terminal 39)
is the same terminal and has the same electrical potential
for analog common and digital common connection.
Resolution on analog output is 12 bit.
6-50 Terminal 42 Output
Option:
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[113]
[114]
[115]
[130]
[131]
[132]
[133]
[134]
[135]
[136]
[137]
*
[139]
®
is a registered Danfoss trademark
Function:
Select the function of Terminal 42 as
an analog current output. A motor
current of 20 mA corresponds to
I .
max
No operation
Output freq. 0-100 0 - 100 Hz, (0-20 mA)
Reference Min-Max Minimum reference - Maximum
reference, (0-20 mA)
Feedback +-200% -200% to +200% of 20-14 Maximum
Reference/Feedb., (0-20 mA)
Motor cur. 0-Imax 0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
Torque 0-Tlim 0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
Power 0-Pnom 0 - Motor rated power, (0-20 mA)
Speed 0-HighLim 0 - Speed High Limit (4-13 Motor
Speed High Limit [RPM] and
4-14 Motor Speed High Limit [Hz]),
(0-20 mA)
Ext. Closed Loop 1 0 - 100%, (0-20 mA)
Ext. Closed Loop 2 0 - 100%, (0-20 mA)
Ext. Closed Loop 3 0 - 100%, (0-20 mA)
Out frq 0-100 0 - 100 Hz
4-20mA
Reference 4-20mA Minimum Reference - Maximum
Reference
Feedback 4-20mA -200% to +200% of 20-14 Maximum
Reference/Feedb.
Motor cur. 4-20mA 0 - Inverter Max. Current (16-37 Inv.
Max. Current)
Torq.0-lim 4-20 mA 0 - Torque limit (4-16 Torque Limit
Motor Mode)
Torq.0-nom 0 - Motor rated torque
4-20mA
Power 4-20mA 0 - Motor rated power
Speed 4-20mA 0 - Speed High Limit (4-13 and 4-14)
Bus ctrl. 0 - 100%, (0-20 mA)
