Parameter Description
4-17 Torque Limit Generator Mode
Range: Function:
100.0 [ 0.0 - Enter the maximum torque limit for
% 1000.0 %] generator mode operation. The torque
*
limit is active in the speed range up to
and including the rated motor speed
(1-25 Motor Nominal Speed). Refer to
14-25 Trip Delay at Torque Limit for further
details.
If a setting in 1-00 Configuration Mode to
1-28 Motor Rotation Check is changed,
4-17 Torque Limit Generator Mode is not
automatically reset to the default settings.
4-18 Current Limit
Range: Function:
Size [ 1.0 - Enter the current limit for motor and
related 1000.0 %] generator operation. To protect the motor
*
from reaching the stalling torque, the
default setting is 1.1 x the rated motor
current (set in 1-24 Motor Current). If a
setting in 1-00 Configuration Mode to
1-28 Motor Rotation Check is changed,
4-16 Torque Limit Motor Mode to
4-18 Current Limit are not automatically
reset to the default settings.
4-19 Max Output Frequency
Range: Function:
Size [ 1.0 - Enter the maximum output frequency
related 1000.0 value. 4-19 Max Output Frequency specifies
*
Hz] the absolute limit on the frequency
converter output frequency for improved
safety in applications where accidental
over-speeding must be avoided. This
absolute limit applies to all configurations
and is independent of the setting in
1-00 Configuration Mode. This parameter
cannot be adjusted while the motor is
running.
When 1-10 Motor Construction is set to [1]
PM non salient SPM the maximum value is
limited to 300Hz.
®
VLT HVAC Drive Programming Guide
3.6.2 4-5* Adj. Warnings
Define adjustable warning limits for current, speed,
reference and feedback.
NOTE
Not visible in display, only in VLT Motion Control Tool,
MCT 10.
Warnings are shown on display, programmed output or
serial bus.
(P 4-18)
(P 4-51)
(P 4-50)
4-50 Warning Current Low
Range:
0.00 A
4-51 Warning Current High
Range:
Size
related
4-52 Warning Speed Low
Range:
0 RPM
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
I
motor
I ON REF
LIM
I
HIGH
IN RANGE
I
LOW
n n
REF
MIN LOW
(P 4-11) (P 4-52) (P 4-53)
Function:
[ 0.00 - Enter the I
*
LOW
par. 4-51 A]
current falls below this limit (I
display reads CURRENT LOW. The signal
outputs can be programmed to produce a
status signal on terminal 27 or 29 and on
relay output 01 or 02. Refer to .
Function:
[ par. 4-50 Enter the I
- par. 16-37 current exceeds this limit (I
*
A]
display reads CURRENT HIGH. The
signal outputs can be programmed to
produce a status signal on terminal 27
or 29 and on relay output 01 or 02.
Refer to .
[ 0 - par. 4-53 RPM]
*
n
[RPM]
motor
n n
HIGH MAX
(P 4-13)
value. When the motor
), the
LOW
value. When the motor
HIGH
), the
HIGH
Function:
