Parameter Description
9-53 Profibus Warning Word
Range: Function:
0 [0 - 65535 ] This parameter displays Profibus communi-
*
cation warnings. Please refer to the Profibus
Operating Instructions for further information.
Read only
Bit: Meaning:
0 Connection with DP-master is not ok
1 Not used
2 FDLNDL (Fieldbus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initialisation of PROFIBUS is not ok
8 Frequency converter is tripped
9 Internal CAN error
10 Wrong configuration data from PLC
11 Wrong ID sent by PLC
12 Internal error occured
13 Not configured
14 Timeout active
15 Warning 34 active
9-63 Actual Baud Rate
Option: Function:
This parameter displays the actual
Profibus baud rate. The Profibus
Master automatically sets the baud
rate.
[0] 9,6 kbit/s
[1] 19,2 kbit/s
[2] 93,75 kbit/s
[3] 187,5 kbit/s
[4] 500 kbit/s
[6] 1500 kbit/s
[7] 3000 kbit/s
[8] 6000 kbit/s
[9] 12000 kbit/s
[10] 31,25 kbit/s
[11] 45,45 kbit/s
[255] No baudrate found
*
9-65 Profile Number
Range: Function:
0 [0 - 0 ] This parameter contains the profile identification.
*
Byte 1 contains the profile number and byte 2 the
version number of the profile.
NOTE
This parameter is not visible via LCP.
®
VLT HVAC Drive Programming Guide
9-70 Programming Set-up
Option:
[0]
[1]
[2]
[3]
[4]
[9]
This parameter is unique to LCP and fieldbuses. See also
0-11 Programming Set-up.
9-71 Profibus Save Data Values
Option:
[0]
[1]
[2]
9-72 ProfibusDriveReset
Option:
[0]
[1]
[3]
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Function:
Select the set-up to be edited.
Factory setup Uses default data. This option can be used
as a data source to return the other set-ups
to a known state.
Set-up 1 Edits Set-up 1.
Set-up 2 Edits Set-up 2.
Set-up 3 Edits Set-up 3.
Set-up 4 Edits Set-up 4.
Active Set-up Follows the active set-up selected in
*
0-10 Active Set-up.
Function:
Parameter values changed via Profibus are not
automatically stored in non-volatile memory.
Use this parameter to activate a function that
stores parameter values in the EEPROM non-
volatile memory, so changed parameter values
will be retained at power-down.
Off Deactivates the non-volatile storage function.
*
Store all Stores all parameter values for all set-ups in the
setups non-volatile memory. The selection returns to
Off [0] when all parameter values have been
stored.
Store all Stores all parameter values for all set-ups in the
setups non-volatile memory. The selection returns to
Off [0] when all parameter values have been
stored.
Function:
No action
*
Power-on Resets frequency converter upon power-up,
reset as for power-cycle.
Comm option Resets the Profibus option only, useful after
reset changing certain settings in parameter
group 9-**, e.g. 9-18 Node Address.
When reset, the frequency converter
disappears from the fieldbus, which may
cause a communication error from the
master.
3 3
