Parameter Description
16-56 Feedback 3 [Unit]
Range:
0.000
ProcessCtrlUnit
3
3
16-58 PID Output [%]
Range:
0.0 %
[0.0 - 100.0 %] This parameter returns the Drive Closed
*
3.16.4 16-6* Inputs and Outputs
16-60 Digital Input
Range:
Function:
0
[0 -
View the signal states from the active digital inputs.
1023 ]
Example: Input 18 corresponds to bit no. 5, '0' = no
*
signal, '1' = connected signal. Bit 6 works in the
opposite way, on = '0', off = '1' (safe stop input).
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10-63
122
Function:
[-999999.999 -
View value of Feedback 3,
999999.999
see parameter group 20-0*
*
ProcessCtrlUnit]
Feedback.
The value is limited by
settings in 20-13 Minimum
Reference/Feedb. and
20-14 Maximum Reference/
Feedb.. Units as set in
20-12 Reference/Feedback
Unit.
Function:
Loop PID controller output value in
percent.
Digital input term. 33
Digital input term. 32
Digital input term. 29
Digital input term. 27
Digital input term. 19
Digital input term. 18
Digital input term. 37
Digital input GP I/O term. X30/4
Digital input GP I/O term. X30/3
Digital input GP I/O term. X30/2
Reserved for future terminals
MG.11.CC.02 - VLT
®
VLT
HVAC Drive Programming Guide
16-61 Terminal 53 Switch Setting
Option:
[0] Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-62 Analog Input 53
Range:
0.000
*
16-63 Terminal 54 Switch Setting
Option:
[0] Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-64 Analog Input 54
Range:
0.000
*
16-65 Analog Output 42 [mA]
Range:
0.000
*
16-66 Digital Output [bin]
Range:
0
[0 - 15 ]
*
16-67 Pulse Input #29 [Hz]
Range:
0
[0 - 130000 ] View the actual frequency rate on terminal
*
16-68 Pulse Input #33 [Hz]
Range:
0
[0 - 130000 ] View the actual value of the frequency
*
®
is a registered Danfoss trademark
Function:
View the setting of input terminal 53. Current =
0; Voltage = 1.
Function:
[-20.000 - 20.000 ]
View the actual value at input 53.
Function:
View the setting of input terminal 54. Current =
0; Voltage = 1.
Function:
[-20.000 - 20.000 ]
View the actual value at input 54.
Function:
[0.000 -
View the actual value at output 42 in
30.000 ]
mA. The value shown reflects the
selection in 6-50 Terminal 42 Output.
Function:
View the binary value of all digital outputs.
Function:
29.
Function:
applied at terminal 33 as an impulse input.
