Parameter Description
[62] Reset Counter Input for reset of counter A.
A
[63] Counter B (up) (Terminal 29 and 33 only) Input for
increment counting in the SLC counter.
[64] Counter B (Terminal 29 and 33 only) Input for
(down) decrement counting in the SLC counter.
[65] Reset Counter Input for reset of counter B.
B
[66] Sleep Mode Forces frequency converter into Sleep Mode
(see parameter group 22-4*). Reacts on the
rising edge of signal applied!
[68] Timed Actions Timed actions are disabled. See parameter
Disabled group 23-0* Timed Actions.
[69] Constant OFF Timed Actions are set for Constant OFF. See
parameter group 23-0* Timed Actions.
[70] Constant ON Timed Actions are set for Constant ON. See
parameter group 23-0* Timed Actions.
[78] Reset Resets all data in 16-96 Maintenance Word
Preventive to 0.
Maintenance
Word
[80] PTC Card 1 All Digital Inputs can be set to PTC Card 1
[80]. However, only one Digital Input must
be set to this choice.
5-10 Terminal 18 Digital Input
Same options and functions as parameter group 5-1*, except for
Pulse input.
Option:
[8] Start
*
5-11 Terminal 19 Digital Input
Same options and functions as parameter group 5-1*, except for
Pulse input.
Option:
[0] No operation
*
5-12 Terminal 27 Digital Input
Option: Function:
[2] Coast inverse Functions are described under parameter
*
group 5-1* Digital Inputs
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for only.
[14] Jog Functions are described under 5-1* Digital Inputs
*
5-14 Terminal 32 Digital Input
Option: Function:
[0] No Operation Same options and functions as parameter
*
group 5-1* Digital Inputs, except for Pulse
input.
®
VLT HVAC Drive Programming Guide
5-15 Terminal 33 Digital Input
Option:
[0]
5-16 Terminal X30/2 Digital Input
This parameter is active when option module MCB 101 is
installed in the frequency converter. Same options and functions
as parameter group 5-1* except for Pulse input [32].
Option:
[0]
5-17 Terminal X30/3 Digital Input
This parameter is active when option module MCB 101 is
installed in the frequency converter. Same options and functions
as parameter group 5-1* except for Pulse input [32].
Option:
[0]
5-18 Terminal X30/4 Digital Input
This parameter is active when option module MCB 101 is
installed in the frequency converter. Same options and functions
as parameter group 5-1* except for Pulse input [32].
Option:
[0]
5-19 Terminal 37 Safe Stop
Option:
Function:
[1]
*
[3]
Function:
[4]
[5]
[6]
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Function:
No Operation Same options and functions as parameter
*
group 5-1* Digital Inputs.
No operation
*
No operation
*
No operation
*
Function:
Safe Stop Coasts frequency converter when safe stop is
Alarm activated. Manual reset from LCP, digital
input or fieldbus.
Safe Stop Coasts frequency converter when safe stop is
Warning activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset.
PTC 1 Alarm Coasts frequency converter when safe stop is
activated. Manual reset from LCP, digital
input or fieldbus. Choice 4 is only available
when the MCB 112 PTC Thermistor Card is
connected.
PTC 1 Coasts frequency converter when safe stop is
Warning activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset, unless a
Digital Input set to PTC Card 1 [80] is still
enabled. Choice 5 is only available when the
MCB 112 PTC Thermistor Card is connected.
PTC 1 & This choice is used when the PTC option is
Relay A gated together with a Stop button through a
Safety relay to T-37. Coasts frequency
converter when safe stop is activated. Manual
reset from LCP, digital input or fieldbus.
Choice 6 is only available when the MCB 112
PTC Thermistor Card is connected.
