Danfoss VLT Series Programming Manual page 99

Parameter Description
13-01 Start Event
Option:
[22] Comparator 0
[23] Comparator 1
3 3
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
98
®
VLT HVAC Drive Programming Guide
Function:
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the
logic rule.
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
Use the value of DI32 in the logic rule
(High = TRUE).
Use the value of DI33 in the logic rule
(High = TRUE).
This event is TRUE if the frequency
converter is started by any means
(either via digital input, field bus or
other).
This event is TRUE if the frequency
converter is stopped or coasted by
any means (either via digital input,
fieldbus or other).
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and the reset button is
pressed.
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
This event is TRUE if the OK key on
the LCP is pressed.
MG.11.CC.02 - VLT
13-01 Start Event
Option:
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
13-02 Stop Event
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current
range
®
is a registered Danfoss trademark
Function:
This event is TRUE if the Reset key on
the LCP is pressed.
This event is TRUE if the Left key on
the LCP is pressed.
This event is TRUE if the Right key on
the LCP is pressed.
This event is TRUE if the Up key on
the LCP is pressed.
This event is TRUE if the Down key on
the LCP is pressed.
Use the result of comparator 4 in the
logic rule.
Use the result of comparator 5 in the
logic rule.
Use the result of logic rule 4 in the
logic rule.
Use the result of logic rule 5 in the
logic rule.
Function:
Select the boolean (TRUE or FALSE)
input to deactivate Smart Logic
Control.
Enters the fixed value of FALSE in the
logic rule.
Enters the fixed value TRUE in the
logic rule.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
