Danfoss VLT Series Programming Manual page 91

Parameter Description
9-23 Parameters for Signals
Array [1000]
Option:
[1601] Reference [Unit]
[1602] Reference [%]
3 3
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1622] Torque [%]
[1626] Power Filtered [kW]
[1627] Power Filtered [hp]
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1652] Feedback [Unit]
[1653] Digi Pot Reference
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Pulse Input #29 [Hz]
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
90
®
VLT HVAC Drive Programming Guide
9-23 Parameters for Signals
Array [1000]
Function: Option:
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[1850] Sensorless Readout [unit]
[2013] Minimum Reference/Feedb.
[2014] Maximum Reference/Feedb.
[2021] Setpoint 1
[2022] Setpoint 2
[2023] Setpoint 3
[2643] Terminal X42/7 Bus Control
[2653] Terminal X42/9 Bus Control
[2663] Terminal X42/11 Bus Control
9-27 Parameter Edit
Option:
[0]
[1]
*
9-28 Process Control
Option:
[0]
[1]
*
®
MG.11.CC.02 - VLT is a registered Danfoss trademark
Function:
Parameters can be edited via Profibus, the
standard RS485 interface, or the LCP.
Disabled Disables editing via Profibus.
Enabled Enables editing via Profibus.
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via
either Profibus or standard fieldbus but not
both simultaneously. Local control is always
possible via the LCP. Control via process control
is possible via either terminals or fieldbus
depending on the settings in 8-50 Coasting
Select to 8-56 Preset Reference Select.
Disable Disables process control via Profibus, and
enables process control via standard fieldbus or
Profibus Master class 2.
Enable Enables process control via Profibus Master Class
cyclic 1, and disables process control via standard
master fieldbus or Profibus Master class 2.
Function:
