5 Display / WBM Configuration
WBM: "Current Parameters"
You can set the parameter bits on this page. The bits are sent when you click the
"Apply" button. The parameter echo is returned.
Parameter
Parameter bits Enables/disables the following parameter bits:
Bit 3 / Bit 2 / Bit 1 / Bit 0
Parameter echo The AS-i slave transfers its current parameter value in the response (parameter
echo displayed).
5.2.15.5

String Transfer

Calls can be transferred to the slave with the "String Transfer" function. The
messages returned by the slave are displayed.
Note
Note that changes remain only until the PROFINET IO controller starts up. If a
PROFINET IO controller is connected, the values are overwritten again
immediately.
Note
Not all slaves support string transfer. To find out which functions your slave
supports, refer to the data sheets of the slave.
Keypad/Display
AS-i Line 1 > Lifelist > Display...
IE/AS−INTERFACE LINK PN IO
94
Function
Config. > Change configuration
Parameter > Change parameters
Bin. I/O > Change binary Inputs/outputs
Analog > Change analog inputs/outputs
Status
Statistics > Reset all counters
Statistics > Reset all counters
String transfer > Write (string transfer to slave)
as of hardware version 1, as of firmware version V2.0
(select slave and "OK")
Release 08/2018
C79000−G8976−C216−03
