A AS-Interface Protocol Implementation Conformance Statement (PICS)
Table A-2 , (Fortsetzung)
No. Function or Call on the Host Interface
(symbolic representation)
22.2 Status, Resp =
Cmd_Read_IO_Configuration(Addr,
CONF)
22.3 Status, Resp =
Cmd_Read_Identification_Code(Addr,
IDCOD)
22.4 Status, Resp = Cmd_Read_Status(Addr,
STAT)
22.5 Status, Resp =
Cmd_Read_Reset_Status(Addr,
STATRES)
22.6 Status, Resp =
Cmd_Read_Ext_ID-Code_1(Addr,
IDCOD1)
22.7 Status, Resp =
Cmd_Read_Ext_ID-Code_2(Addr,
IDCOD2)
23 Status, S_List = Get_LPF()
24 Status =
Write_Extended_ID-Code_11(S_Ext_ID-C
ode_1)
25 AImage, Status = Read_AIDI()
26 Status = Write_AODI(AImage)
27 String, Status = Read_ParamStr(S_Addr)
28 Status = Write_ParamStr(S_Addr, String)
29 String, Status = Read_DiagStr(S_Addr)
30 String, Status = Read_IdentStr(S_Addr)
Part B Supported Slave Profiles
1 Support of extended address mode
2 Support of Combined transaction type 1
integrated (S-7.3 only)
3 Full support of Combined transaction
type 1 integrated
4 Support of Combined transaction type 2
integrated
5 Support of Combined transaction type 3
integrated
6 Support of Combined transaction type 4
integrated
IE/AS−INTERFACE LINK PN IO
184
M4 Comment / Function implemented by / see
Section
X see Section 8.2
X see Section 8.2
X see Section 8.2
− optional call
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X see Section 8.2
X
X
X Only profiles 7.3/7.4 are supported.
X
X
X
as of hardware version 1, as of firmware version V2.0
