Current Parameters - Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO Manual

WBM: "Cyclic Data" Tab
Parameter
Binary inputs Bit 3 / Bit 2 / Bit 1 / Bit 0
Binary outputs Enables/disables the following output bits: Bit 3 / Bit 2 / Bit 1 / Bit 0
Analog inputs Channel 1 / Channel 2 / Channel 3 / Channel 4
Analog outputs Entry of the value to be written on channel x.
Channel 1 / Channel 2 / Channel 3 / Channel 4
5.2.15.4

Current Parameters

With the "Parameters" display menu or the "Current Parameters" WBM tab, you
can change the current parameters of a slave and transfer the changed values to
the slave.
Note
Note that changes remain only until the PROFINET IO controller starts up. There
is then a restart with the configured parameter values. If the PROFINET IO
controller is connected, the values are overwritten only when the controller next
starts up.
Keypad/Display
AS-i Line 1 > Lifelist > Display...
or
AS-i Line 1 > Slave Info > Display... (select slave and "OK")
For information on navigating in the menus and working with the buttons, refer to
Section 5.2.15.3.
Apart from the current values, the "Parameters" menu shows the echo of the slave.
Below the "Echo" box, there are boxes for entering parameters. Navigate to the
relevant value with the "right"/"left" cursor buttons.
Change the values with the "up"/"down" cursor keys. To transfer the changed
values to the slave, press the "OK" button.
IE/AS−INTERFACE LINK PN IO
Release 08/2018
C79000−G8976−C216−03
Config.
Parameter
Config.
Parameter
as of hardware version 1, as of firmware version V2.0
5 Display / WBM Configuration
Function
(select slave and "OK")
> Change configuration
> Change parameters
> Change configuration
> Change parameters
93
