5.2.11.4
Error
WBM: "Error" Tab − counting and evaluation of transmission errors
This page displays information on any errors that may have occurred and allows
diagnostics.
If you click on an entry, the Packet Error Statistics graphic is displayed. You then
see a configurable graphical representation of the counter value.
Parameter
Port
LAN interface of the IE/AS-i LINK (1 or 2)
CRC
Number of packets with a valid length but bad checksum
Undersize
Number of packets that were too short with valid checksum
Oversize
Number of packets that were too long with valid checksum
Jabbers
Number of packets that were too long without valid checksum
Collisions
Number of collisions that occurred
IE/AS−INTERFACE LINK PN IO
Release 08/2018
C79000−G8976−C216−03
as of hardware version 1, as of firmware version V2.0
5 Display / WBM Configuration
Function
79
