8 Using the Data Record Interface
Flag 1
Bit Number Meaning
0 CONFIG_OK
1 LDS_0
2 AUTO_ADDR_ASSIGN
3 AUTO_ADDR_AVAIL
4 CONFIG_MODE
5 NORMAL_MODE
6 APF
7 OFFLINE_READY
The meaning of the flags is the same as in the "Get_LPS_LAS_LDS_LPF_Flags"
job, Section 8.2.1.4).
IE/AS−INTERFACE LINK PN IO
136
Flag 2
Bit Number
0
1
2
3
4
5
6
7
as of hardware version 1, as of firmware version V2.0
Meaning
PERIPHERY_OK
DATA_EXCHANGE_ACTIVE
OFFLINE
AUTO_ADDR_ENABLE
Ground short
EPROM_OK
reserved
reserved
