5 Display / WBM Configuration
5.2.15.3

Cyclic Data

The display menus "Bin. I/O" and "Analog" and the WBM tabs "Cyclic Data" display
the cyclic input/output data of the AS-i slave. The output data of the slave can also
be modified here during commissioning. This allows the complete I/O test to be
performed for binary or analog slaves without requiring a connection to the
higher-level PROFINET IO controller.
Note
Note that any changes made here remain only until the PROFINET IO controller
starts up and are then overwritten by the process output data. If a PROFINET IO
controller is connected, the values are overwritten again immediately.
Keypad/Display
AS-i Line 1 > Lifelist > display...
or
AS-i Line 1 > Slave Info > Display... (select slave and "OK")
Select a slave with the cursor buttons in the "Lifelist" or "Info" menu. Pressing "OK"
opens the "Config." menu.
From the "Configuration" menu, use the cursor buttons "right"/"left" to change to
the other menus "Parameters", "Bin. I/O", "Analog" etc. With the "up"/"down" cursor
buttons, you change to the next slave. The "OK" button opens the follow-on menu
in which you can change the values.
Navigate to the relevant value with the "right"/"left" cursor buttons.
Change the values with the "up"/"down" cursor keys. To transfer the changed
values to the slave, press the "OK" button.
IE/AS−INTERFACE LINK PN IO
92
Config. > Change configuration
Parameter > Change parameters
Bin. I/O > Change binary Inputs/outputs
Analog > Change binary inputs/outputs
Config. > Change configuration
...
as of hardware version 1, as of firmware version V2.0
(select slave and "OK")
