5 Display / WBM Configuration
5.2.12 Navigation "PROFINET IO −> Status"
This page displays information on PROFINET IO.
5.2.12.1

Status

Keypad/Display
PROFINET > Info > Device name > Change PROFINET device name
PROFINET > Error
WBM: "Status" Tab
Parameter
PNIO device name
Controller IP address
Controller name
Connection status
Controller status
Update time
IE/AS−INTERFACE LINK PN IO
80
IP address Controller
Controller name (PROFINET device name of controller)
Connection (AR status online/offline)
Controller (Controller status RUN/STOP)
Update time [ms]
Displays the PROFINET device name of the link
Displays the IP address of the PROFINET IO controller
Displays the PROFINET device name of the controller
Display of the connection status (online / offline) between link and
PROFINET IO controller. See also Section 8.2.1.8.
Display of the operating state of the controller (RUN / STOP)
Display of the set update time in milliseconds
as of hardware version 1, as of firmware version V2.0
Function
