8.2.1.3 Set_LPS
Meaning
This call transfers the list of configured AS-i slaves for non-volatile storage in the
EEPROM of the master or in the C-PLUG, if it is inserted. When this call is
executed, the AS-i master changes to the offline phase and then changes back to
the normal mode (warm restart on the AS-i master).
The call is not executed in protected mode.
Note
If you use CPUs from the SIMATIC S7 system as the PROFINET IO controller,
then dependent on the configuration in STEP 7, these may send a complete AS-i
slave configuration to the IE/AS-i LINK during startup. Use of the call described
here is then generally unnecessary.
Structure of the RecordDataWrite service − Index 12
Byte
Bit 7
0
1
2 Slave Slave
7/7A
3 Slave Slave
15/15A 14/14A
4 Slave Slave
23/23A 22/22A
5 Slave Slave
31/31A 30/30A
6 Slave Slave
7B
7 Slave Slave
15B
8 Slave Slave
23B
9 Slave Slave
31B
10
11
The bits in the LPS data have the following meaning: 0 = AS-i slave not configured;
1 = AS-i slave configured.
