Keys
[Shift]+[V-set]
(Config)
[Shift]+[I-set]
(Function)
[Shift]+[P-set]
(System)
[Shift]+[Recall]
(Save)
[Shift]+[1] (Log)
[Shift]+[2] (Lock)
[Shift]+[3] (Local)

1.4 Push-on Knob

This series High power Programmable DC Power Supply provides a knob on
the front panel as shown in the next figure.
The functions of the posh-on knob is described as follows.
•
•
•
Adjust the Value Setting
In the value setting interface, rotate the knob clockwise to increase the set value
and anticlockwise to decrease the set value.
Select Menu Item
The knob can also be used to view menu items. In the menu item display inter-
face, turning the knob clockwise indicates that the next menu item is selected,
Description
Enter to Configuration menu.
Enter the Function menu.
Enter the System menu.
Save the common parameter settings.
Enter the data logging function menu.
Turn the keyboard lock on or off.
Switch remote control mode to local control mode.
Adjust the value setting
Select menu item
Confirm the set value or the selected menu item
