Specifications of Red and Black Test Lines

ITECH provides you with optional red and black test lines, the user can choose
the company's test line for testing. For specifications of ITECH test lines and
maximum current values, refer to the table below.
Model
IT-E30110-AB
IT-E30110-BB
IT-E30110-BY
IT-E30312-YY
IT-E30320-YY
IT-E30615-OO
IT-E31220-OO
IT-E32410-OO
IT-E32420-OO
IT-E33620-OO
For maximum current of AWG copper wire, refer to table blow.
AWG
The
Maximum
current
value( A)
Note: AWG (American Wire Gage), it means X wire ( marked on the wire).
The table above lists current capacity of single wire at working
temperature of 30°C. For reference only.
Specifi Length
cations
10A 1m
10A 1m
10A 1m
30A 1.2m
30A 2m
60A 1.5m
120A 2m
240A 1m
240A 2m
360A 2m
10 12 14 16
40 25 20 13
Copyright ©ITECH Electronic Co., Ltd.

Appendix

Description
Alligator clips-Banana plugs A
pair of red and black test line
Banana plugs - Banana plugs A
pair of red and black test line
Banana plugs - Y-type terminals
A pair of red and black test line
Y-type terminals - A pair of red
and black test line
Y-type terminals - A pair of red
and black test line
Ring terminals - A pair of red and
black test line
Ring terminals - A pair of red and
black test line
Ring terminals - A pair of red and
black test line
Ring terminals - A pair of red and
black test line
Ring terminals - A pair of red and
black test line
18 20 22 24
10 7 5 3.5 2.5 1.7
