Table 54 – Chart Recorder Output – Calculation Formula For The Parameter Lin +0 - LEYBOLD GRAPHIX ONE Instruction Manual

Lin +0
Linear representation, U = 10 V corresponds to p = 10
All sensor types
Table 54 – Chart recorder output – Calculation formula for the parameter Lin +0
Lin +1
Linear representation, U = 10 V corresponds to p = 10
All sensor types
Table 55 – Chart recorder output – Calculation formula for the parameter Lin +1
Lin +2
Linear representation, U = 10 V corresponds to p = 10
All sensor types
Table 56 – Chart recorder output – Calculation formula for the parameter Lin +2
Lin +3
Linear representation, U = 10 V corresponds to p = 10
All sensor types
Table 57 – Chart recorder output – Calculation formula for the parameter Lin +3
IM221
Logarithmic representation IM221 Controller (1 V / decade). U = 8 V corresponds to
-2
p = 10 mbar.
Controller
IM221
Table 58 – Chart recorder output – Calculation formula for the parameter IM221
90
Sensor
Sensor
Sensor
Sensor
0
mbar.
Pressure [mbar]
0
p = U/10 * 10
1
mbar.
Pressure [mbar]
1
p = U/10 * 10
2
mbar.
Pressure [mbar]
2
p = U/10 * 10
3
mbar.
Pressure [mbar]
3
p = U/10 * 10
Pressure [mbar]
p = 10^[U – 10]
GA300550402_002_C1 – 10/2016
