Symbols; Symbols For The Controls - LEYBOLD GRAPHIX ONE Instruction Manual

6.1.4

Symbols

6.1.4.1

Symbols for the Controls

Symbol Designation
Next
Previous
Up
Down
Return
OK
Configuration
Display Mode
Normal
Big
Chart
Leak Test
Speedo Channel 1
Speedo Channel 2
Speedo Channel 3
Scale up
Scale down
Start
■
Stop
HV On
HV Off
36
Next menu page
Previous menu page
Scroll upward in the selection list
Scroll downward in the selection list
Return to the previous display
Accept / confirm
Start the main menu
Change display mode
Enabling display mode Normal
Enabling display mode Big
Enabling display mode Chart
Enabling display mode Leak Test
Enabling display mode Speedo for channel 1
Enabling display mode Speedo for channel 2
Enabling display mode Speedo for channel 3
Zoom out time scale
Zoom in time scale
Start a function
Stop a function
Switch high vacuum measurement circuit on
Switch high vacuum measurement circuit off
Explanation
GA300550402_002_C1 – 10/2016
