Zero Alignment (Zero Adjust)

Pressing the button Set, aligns the zero level of the connected sensor.
NOTICE:
Switch the offset correction facility off before setting up the zero level for a
sensor.
NOTICE:
To utilise this function, CERAVAC sensors of CTR100 series and CTR101
series must be connected using a 15-way SUB-D cable connected to the
connections C2, D2 or E2 at the rear of the instrument
26).
