Display; Display Mode; Resolution; Brightness - LEYBOLD GRAPHIX ONE Instruction Manual

7.4

Display

7.4.1

Display Mode

This parameter controls the way in which data is displayed.
Normal
Big
Chart
Leak Test
Speedo Channel 1
Speedo Channel 2
Speedo Channel 3
Table 34 – Values for the parameter Display mode
7.4.2

Resolution

This parameter controls the resolution for the measured values display.
Standard
High
Table 35 – Values for the parameter Display digits
7.4.3

Brightness

This parameter controls the brightness of the display.
Low
Medium
High
Table 36 – Values for the parameter Brightness
84
Display
Display
Display
Explanation
Measured values and status display
Large display of measured data
Graph of the pressure history
Leak rate determination
Speedometer-shaped display of channel 1 pressure
Speedometer-shaped display of channel 2 pressure
Speedometer-shaped display of channel 3 pressure
Explanation
Default resolution
High resolution
Explanation
Low display brightness
Medium display brightness
High display brightness
GA300550402_002_C1 – 10/2016
