General Description of the Instrument

3.
3.1

GRAPHIX controller

The GRAPHIX controller is a display and operating unit with a graphic user interface for
sensors with an analogue or digital interface of the company Leybold GmbH or from other
manufacturers. Depending on the version, the unit offers one or several channels, and it is
used in combination with the sensors from the series THERMOVAC, IONIVAC,
PENNINGVAC and CERAVAC as well as DU sensors for the measurement of pressures
above and below atmospheric pressures (vacuum). It is also possible to use sensors made
by other manufacturers by entering a variable analogue logarithmic or analogue linear
characteristic ranging from 0 – 10 Volt. Operate all connected sensors in agreement with
the information given in the corresponding Operating Instructions.
3.2

Suitable Sensors

The following sensors can be operated with the GRAPHIX controller:
Sensor
THERMOVAC
THERMOVAC
IONIVAC
PENNINGVAC
PENNINGVAC
CERAVAC
DU sensor
DU relative pressure sensor
Further sensors
Table 2 – Suitable sensors
GA300550402_002_C1 – 10/2016
Typ
TTR81N
TTR90 / TTR91 / TTR91N
TTR96S / TTR96SN
TTR211 / TTR216S
TTR911 / TTR911N
TTR916 / TTR916N
TTR911N (RS232)
TTR100 / TTR100S2
TTR101 / TTR101N
TTR101S2 / TTR101S2N
TTR101N (RS232)
TTR200N (RS232)
ITR90 / ITR90N
ITR200S / ITR200SN
ITR200SL / ITR200SLN
PTR81N
PTR225 / PTR225N
PTR225S / PTR225SN
PTR237 / PTR237N
PTR225N (RS232)
PTR82N
PTR90 / PTR90N
PTR90N (RS232)
PTR200N (RS232)
CTR90 / CTR91
CTR100 / CTR100N
CTR101 / CTR101N
DU200 / DU201
DU2000 / DU2001
DU2001 rel.
Corresponding to characteristics
Anzeige
TTR... (TTR?)
TTR911N_D
TTR... (TTR10X)
TTR101N_D
TTR200N
ITR...
PTR... (PTR?)
PTR225N_D
PTR... (PTR90?)
PTR90N_D
PTR200N
CTR... (CTR?)
DU...
DUrel
CUSTOM
