7.3.2

Key Tone

Through this parameter you define whether or not an audible signal shall be output when
operating a button.
Off
On
Table 30 – Values for the parameter Key Tone
7.3.3

Error Relay

With the aid of this parameter you define for which error type the error signal relay shall
switch. Select the required relay output: no separate labelling = N.O. (Normally Open) or
N.C. (Normally Closed).
All
Only Device
Channel 1 & Device
Channel 2 & Device
Channel 3 & Device
All N.C.
Only Device N.C.
Channel 1 & Device N.C.
Channel 2 & Device N.C.
Channel 3 & Device N.C.
Table 31 – Values for the parameter Error Relay
7.3.4

Baud Rate (Data Rate)

The baud rate defines the communication speed for the serial interface.
9600
19200
38400
Table 32 – Values for the parameter Data Rate
82
Display
Display
Display
Explanation
Key tone Off
Key tone On
Explanation
All errors
Device errors only
Sensor at Channel 1 and device error
Sensor at Channel 2 and device error
(for GRAPHIX TWO and THREE only)
Sensor at Channel 3 and device error
(for GRAPHIX THREE only)
All errors
Device errors only
Sensor at Channel 1 and device error
Sensor at Channel 2 and device error
(for GRAPHIX TWO and THREE only)
Sensor at Channel 3 and device error
(for GRAPHIX THREE only)
Explanation
9600 Baud
19200 Baud
38400 Baud
GA300550402_002_C1 – 10/2016
