Manual Configuration - SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Management Manual

Manual Configuration

Web – Click System, IP. Specify the management interface, IP
address and default gateway, then click Apply.
CLI – Specify the management interface, IP address and default
gateway.
Console#config
Console(config)#interface vlan 1
Console(config-if)#ip address 10.2.13.30 255.255.255.0
Console(config-if)#exit
Console(config)#ip default-gateway 192.168.1.254
Console(config)#
Using DHCP/BOOTP
If your network provides DHCP/BOOTP services, you can
configure the switch to be dynamically configured by these
services.
Web – Click System, IP. Specify the Management VLAN, set the IP
Address Mode to DHCP or BOOTP. Then click Apply to save your
changes. The switch will broadcast a request for IP configuration
settings on the next power reset. Otherwise, you can click Restart
DHCP to immediately request a new address.
B C
ASIC ONFIGURATION
3-92
3-74
3-76
2-13
