C
ONFIGURING THE
CLI – This example creates trunk 1 with ports 11 and 12. Just
connect these ports to two static trunk ports on another switch to
form a trunk.
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/11
Console(config-if)#channel-group 1
Console(config-if)#exit
Console(config)#interface ethernet 1/12
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type: 1000t
Mac address: 22-22-22-22-22-2c
Configuration:
Name:
Port admin status: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full, 1000full,
Flow control status: Disabled
Port security: Disabled
Port security action: None
Current status:
Created by: User
Link status: Up
Port operation status: Up
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/11, Eth1/12,
Console#

Configuring SNMP

The switch includes an onboard agent that continuously monitors
the status of its hardware, as well as the traffic passing through its
ports, based on the Simple Network Management Protocol
(SNMP). A network management station can access this
information using management software. Access rights to the
onboard agent are controlled by community strings. To
communicate with the switch, the management station must first
2-106
S
WITCH
3-92
3-92
3-178
