CLI – The following example enables LACP for ports 10 and 11.
Just connect these ports to two LACP-enabled trunk ports on
another switch to form a trunk.
Console(config)#interface ethernet 1/10
Console(config-if)#lacp
Console(config-if)#exit
Console(config)#interface ethernet 1/11
Console(config-if)#lacp
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type: 1000t
Mac address: 22-22-22-22-22-2d
Configuration:
Name:
Port admin status: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full, 1000full,
Flow control status: Disabled
Port security: Disabled
Port security action: None
Current status:
Created by: Lacp
Link status: Up
Port operation status: Up
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/10, Eth1/11,
Console#

Statically Configuring a Trunk

Command Usage
• When configuring static trunks, you may not be able to link
switches of different types, depending on the manufacturer's
implementation. The static trunks on this switch are Cisco
EtherChannel compatible.
• To avoid creating a loop in the network, be sure you add a
static trunk via the configuration interface before connecting
the ports, and also disconnect the ports before removing a
static trunk via the configuration interface.
