For more information on NTP servers, clients, and Stratums see "NTP Servers and Peers" on
page 86.
The NTP Throughput panel
... shows two graphs depicting the rate of NTP traffic from Clients and Server/Peers.
The Actions panel
... is in the top left-hand corner of the NTP screen comprises the following buttons:
CHAPTER •
2 VersaSync User Manual Rev. 6.0
The INFO icon opens a window showing the maximum per second traffic rate from
each.
The graphs maybe saved and downloaded (> ARROW icon), or deleted (> TRASH CAN
icon).
Symmetric Keys : Click here to set up your symmetric keys for MD5 authentication. For
more information on Symmetric Keys, see "Configuring NTP Symmetric Keys" on
page 98.
Access Restrictions : Click here to view, change or delete access restrictions to the NTP net-
work. (See also "NTP Access Restrictions" on page 101.)
Fields in the NTP Access Restrictions table include:
Type
IP Version
IP
IP Mask
Auth only
Enable Query
View NTP Clients : Click here to reveal a table of all the clients your VersaSync is ser-
vicing. (See also "Viewing NTP Clients" on page 81.)
Information for each client includes:
Client IP
Received Packets
Mode
Version
Restriction Flags
Avg Interval
Last Interval
Restore Default NTP Configuration : Click here to restore VersaSync's NTP settings to the
factory default. Any settings you have created previously will be lost. See "Restoring the
Default NTP Configuration" on page 82.
