4.8 Resetting the Unit to Factory Configuration
The System Configuration panel
The System Configuration panel provides the following information:
System —The model name of this unit, and the software version currently installed.
Model —The model number of this unit.
Serial Number —The serial number of this unit.
Power Supply —The type of power supply installed in this unit. This can be AC, DC or
both.
Oscillator —The type of internal timing oscillator installed in this unit.
Timing Processor —The timing processor in use with this unit.
GNSS Receiver —The GNSS receiver in use with this unit.
Option —The optional features also included on this unit.
The Upgrade Log panel
The upgrade log is a running log of system upgrades, used for historical and troubleshooting
purposes. It can be expanded by clicking on the DIAGONAL ARROWS icon in the top-right
corner:
Each log entry is comprised of a unique ID, the date the entry was created, the originator of the
entry, and the actual message. Refresh the log by clicking the CIRCLE ARROWS icon in the top-
right corner. Go to the First, Last, or Previous entries by clicking the corresponding buttons in
the bottom-right corner.
The Disk Status panel
The Disk Status panel provides information on the Compact Flash card memory usage. This
information is relevant for troubleshooting purposes, and when preparing the system for a soft-
ware update.
