2.7 Configuring Network Settings
2.7.9.3 Configuration — General Steps
Ensure that the Ethernet port used for PTP is connected to the network. Navigate to
MANAGEMENT > NETWORK: Network Setup , and verify the STATUS in the Ports panel.
Be sure that valid time and 1PPS references are currently selected: Navigate to
MANAGEMENT > OTHER: Reference Priority , and confirm Reference Priority con-
figuration, and Reference Status . Note that in order to operate properly as a Master
Clock, VersaSync must be synchronized to a non-PTP reference. The built-in GNSS ref-
erence provides all information needed with no user intervention. Should you, however,
be using a different reference, ensure that it transmits the following information.

2.7.10 GPSD Setup

GPSD is a free, open-source package used worldwide to manage GNSS systems and devices.
With GPSD support on a VersaSync, users are able to:
connect to the unit over a network via TCP at the specified port using any GPSD-com-
patable software
receive position and timing information from the GNSS receiver in a consistent format,
and
use the WebUI (or CLI) to configure the GPSD service and view status information.
GPSD can only be configured to track the VersaSync internal u-blox receiver (GDPS does not
currently apply to the internal IMU or gyro for navigation purposes)..
To configure GPSD on the WebUI, navigate to MANAGEMENT > NETWORK > GPSD Setup to
access the GSPD Setup Screen
The GPSD Setup Screen is divided into three panels:
1.
The
110
The proper TAI or UTC time (including the current year).
The current TAI to UTC offset (required even if the reference's time is in TAI).
Pending leap second information at least a day in advance.
GPSD Service panel:
allows you to toggle the service ON or OFF
lists the Service Port
