3.3 Managing References
c.
Adding an Entry to the Reference Status Table
To add a new entry to the Reference Status table:
1.
Navigate to the Configure Reference Priorities screen via MANAGEMENT > OTHER: Refer-
ence Priority .
2.
Click the PLUS icon in the top right-hand corner of the Configure Reference Priorities table.
3.
The Add Reference window will display:
4.
In the Add Reference window, enter:
5.
Click Apply or Submit . ( Submit will close the window.)
Deleting a Reference Entry
To delete an entry from the Reference Status table:
1.
Navigate to the Configure Reference Priorities screen via MANAGEMENT > OTHER: Refer-
ence Priority .
2.
In the Configure Reference Priorities table click the Delete button on the right-hand side of
the entry you wish to delete.
3.
In the pop-up window that opens click OK to confirm.
Reordering Reference Entries
To reorder the priority of a reference entry:
132
The Reference Status panel
The Reference Status panel provides a real time indicator of the status of the
VersaSync's references. It is the same as the Reference Status panel on the
HOME screen of the Web UI.
Priority Level : Assign a priority to the new reference.
Time : Select the time reference.
PPS : Select the PPS reference.
Enabled : Check this box to enable the new reference.
