3.3 Managing References
Manufacturer/Model : The manufacturer and/or model of the GNSS receiver in your Ver-
saSync unit.
Validity : Status indicator lights for TIME and 1PPS signals: " On " (
signal, " Off " (
ates that the monitored 1PPS value fell below a quality threshold and the unit is in fly-
wheel mode.
Receiver Mode:
Receiver Dynamics : (u-blox receivers only); see "Setting GNSS Receiver Dynamics" on
page 155.
Survey Progress : Real-time status:
Number of Tracked Satellites : The number of satellites currently being tracked.
Offset : As set by the user, in nanoseconds.
Antenna Sense :
Position : VersaSync's geographic position by:
Receiver Constellation : GPS/GLONASS/Galileo/BeiDou/QZSS
Client A-GPS Status : A-GPS is ENABLED and running, or DISABLED
Client A-GPS Data : External A-GPS data is AVAILABLE, or UNAVAILABLE
Server A-GNSS Status : The Rinex Server feature is ENABLED and running, or DISABLED
Server A-GNSS Data : A-GPS data is AVAILABLE and can be downloaded by clients, or it
is UNAVAILABLE
Identified Satellite Signal Strengths : Bar graphs for all satellites detected. Color indicates
signal strength.
150
red ) indicates that no valid signal is available. A
Single Satellite : Used in areas with poor GNSS reception.
Standard : Default operating mode for the GNSS receiver.
Mobile : [default] For non-stationary applications.
ACQUIRING (x Satellites)—
SURVEYING (x %)— yellow ; remains at 1% if no satellites are in view
COMPLETE — green
OK ( green )
Open : Check the antenna for the presence of an open.
Short : Check the antenna for the presence of a short circuit.
Latitude : In degrees, minutes, seconds
Longitude : In degrees, minutes, seconds
Altitude : In meters MSL (Mean Sea Level)
red
CHAPTER •
3 VersaSync User Manual Rev. 6.0
green ) indicates a valid
yellow 1PPS light indic-
