Mating Connector Plugs
The table below lists the part numbers for the mating connectors. The connectors can be
ordered through Spectracom or ODU-USA Inc. All connectors are circular ODU AMC
type" connectors.
Table 1-8:
Ref
POWER Power connector,
I/O
ETH
SAASM Optional I/O con-
1.5.5.1 ODU
ETHERNET connector wiring:
POWER connector pinout
CHAPTER •
1 VersaSync User Manual Rev. 6.0
Connector Part Numbers
Description
Spectracom
J240R-0051-
5 pin
I/O connector, 26 J240R-0261-
pin
Ethernet connector, J240R-0161-
16 pin
J240R-0081-
nector, 8 pin
®
ordering contact information (USA):
ODU-USA Inc.
4010 Adolfo Road
Camarillo, CA 93012
United States of America
Phone: +1 (805) 484 0540
Fax: +1 (805) 484 7458
sales@odu-usa.com
Email:
Note: Building the mating cables requires special tools. Contact ODU for cable
assemblies. Be advised that typical lead times are 12 to 16 weeks.
1 through 8: A Ethernet Connect, 4 pairs, 1000bT
9 through 16: B Ethernet Connect, 4 pairs, 1000bT
1; 2: V , 10 to 32 V
Main DC
3: V , 10 to 32 V (Standby Power)
Batt DC
4; 5: Ground return
VersaSync Connector
ODU Part No.
Part No.
GK1YBR-
002Q P05UJ00-000L
GK2YAR-
002F P26UC00-000L
GK1YCR-
002F P16UC00-000L
GK1YDR-
012F P08UF00-000L
1.5 Connectors and their Pinouts
®
Mating (Cable) Connector
Spectracom
ODU Part No.
Part No.
P240R-0051- S11YBR-
002Q P05XJG0-0000
P240R-0261- S12YAR-
002F P26XCD0-0000
P240R-0161- S11YCR-
002F P16XCD0-0000
P240R-0081- S11YDR-
002F P08XFG0-0000
"mil-
