5.3.12.1 Format 9S - Spectracom VersaSync User Manual

E x a m p l e m e s s a g e :
<SOH>DDD:HH:MM:SSQ<CR><LF>
Where:
SOH Start of header (ASCII Character 1)
DDD Day of Year (001-366)
: Colon Separator
HH Hours (00-23)
MM Minutes (00-59)
SS Seconds (00-59) (00-60 for leap second)
Q Time Sync Status [as INPUT]
space = SYNC
'.' = SYNC
'*'=NOT IN SYNC
'#' = NOT IN SYNC
"?" = NOT IN SYNC
Q Time Sync Status [as OUTPUT]
space = Time error is less than time quality flag 1's threshold (TFOM < or = 3)
"." = Time error has exceeded time quality flag 1's threshold (TFOM = 4)
"*" = Time error has exceeded time quality flag 2's threshold (TFOM = 5)
"#" = Time error has exceeded time quality flag 3's threshold (TFOM = 6)
"?" = Time error has exceeded time quality flag 4's threshold OR a reference source is unavailable
(TFOM >=7)
CR Carriage Return (ASCII Character 13)
LF Line Feed (ASCII Character 10)
The leading edge of the first character (

5.3.12.1 Format 9S

Format 9S is a variation of ASCII Format 9 that uses Sysplex compatible fields indicating
sychronization status:
FL_SYNC_SYS_REF_NONE ('X')
FL_SYNC_SYS_REF_YES (' ')
FL_SYNC_SYS_REF_LOST ('F')
VersaSync User Manual
) marks the on-time point of the data stream.
CR
Never been in sync
In sync with a reference
Out of sync, lost reference
APPENDIX
261
